| Product Type | Technical Specification | ||||||
|---|---|---|---|---|---|---|---|
| Solid Door (qty) | 2 | 4 | 6 | ||||
| Model | FM 2DUC/F | FM 4DUC/F | FM 6DUc/F | ||||
| Temperature° Celsius | -15°C to -18°C | ||||||
| External Dimension (WxDxH) (mm) | 670 x 790 x 2080 | 1300 x 790 x 2080 | 1930 x 790 x 2080 | ||||
| Internal Dimension (WxDxH) (mm) | 570 x 640 x 1275 | 1200 x 640 x 1275 | 1830 x 640 x 1275 | ||||
| Gross Volume (L) | 467 | 983 | 1499 | ||||
| Voltage/Frequency (V/HZ) | 240V/ 1 /50Hz | ||||||
| Energy Consumption (kwh/Day) | 5.7 - 6.3 | 8.5 - 9/5 | 12.8 - 14.2 | ||||
| Defrost System | Auto Electric Defrost | ||||||
| Temp. Control | Digital Control | ||||||
| Shelves (PVC) | 4 | 8 | 12 | ||||
| Number of Clips | 16 | 32 | 48 | ||||
| Product Type | Technial Specification | ||||||
|---|---|---|---|---|---|---|---|
| Solid Door (qty) | 2 | 4 | 6 | ||||
| Product Size (WxDxH) (mm) | 670 x 790 x 2080 | 1300 x 790 x 2080 | 1930 x 790 x 2080 | ||||
| Gross Volume (L) | 510 | 1103 | 1706 | ||||
| Voltage/Freqence | 220V/50Hz | ||||||
| Compressor | Tacumseh or Equivalent brand / R404a | ||||||
| Cooling System | Dynamic cooling | ||||||
| Defrosting | Auto defrost with automatic evaporation | ||||||
| Temp. Range | N~ST -15°C to -18°C | ||||||
| Temp. Control | Digital Controller | ||||||
| Evaporator Type | Fin Type evaporator | ||||||
| Condenser Type | Fin Type Condenser | ||||||
| Fan Motors | Reputable brand Evaporator fan motors + Condenser fan motors | ||||||
| Door Type | Heavy Duty Magnetic Solid Door with Self-closing feature | ||||||
| Lighting | Optional | ||||||
| Material Grade | SUS 439 / SUS 304 | ||||||
